BMC URS LT ONE

BMC URS LT ONE
This item is currently not available.

Details

ONE OF A KIND

Experience a new level of gravel riding. Full micro-suspension for truly limitless exploration. URS LT embodies the spirit of adventure while retaining the signature URS silhouette and class-leading performance.

Utilizing cutting-edge bike technologies, the URS LT is designed as a one-of-a-kind high-performance blank slate that provides an adventure-proof ride to suit surface, style, distance, and beyond.

MICRO TRAVEL TECHNOLOGY SUSPENSION FORK
The MTT suspension fork, developed in collaboration with HiRide, delivers 20 mm of plush travel over a spring curve optimized for gravel riding. Dampening more than 46% of the typical impacts experienced when riding gravel. The finetuned suspension performance of the MTT fork adapts to a wide range of terrains, complementing sporty and efficient riding styles while filtering out obstacles for a confidence-inspiring riding feel.

TUNED COMPLIANCE CONCEPT (TCC) GRAVEL
The highest level of compliance through a dedicated carbon layup, D-shape seatpost, and Micro Travel Technology, a lightweight and minimalist suspension system that adds 10mm of travel to the rear stays, for perfect power transfer and control on the most challenging terrain.

GRAVEL+ GEOMETRY
Optimized for a modern, aggressive gravel riding style. URS features a slack 70° head angle to create a long front-end and wheelbase for incredible stability.

RACK AND FENDER COMPATIBLE
Compatibility with lightweight racks and fenders to let you choose your favorite configuration, from adventure riding to commuting.

CABLE ROUTING FOR HUB DYNAMOS
No limits to choosing your ideal light setup, whether for bike packing adventures or year-round commuting.

Geometry

Geometry Chart:
SIZE SmallMediumLargeX-Large
Rider Height CM <170 172-180 178-188 186-196
Top Tube MM (tt) 557 578 591 612
Wheelbase MM (wb) 1041 1064 1081 1105
Seat Tube Angle (sa) 74 74 74 74
Seatpost Length MM 330 380 430 430
Stack MM 538 569 603 641
Trail MM (trail) 77 77 77 77
Rear Center MM (rc) 425 425 425 425
Reach MM (reach) 403 415 419 429
Head Tube MM (ht) 113 146 172 207
Head Angle (ha) 70 70 70 70
BB Drop MM (drop) 69 69 69 69
Stem Length MM 70 70 80 90
Seat Tube MM (st) 431 459 492 527
Crank Length MM 170 172.5 172.5 175
Fork Rake MM (fr) 45 45 45 45
Front Center MM (fc) 625 648 665 700
Fork Length MM (fl) 407 407 407 407
Bar Width MM 42 42 44 44
Bar Reach MM 80 80 80 80
Bar Drop MM 120 120 120 120
Standover Height mm 748 778 810 846

Specs

Frame URS Premium Carbon with Micro Travel Technology, Tuned Compliance Concept Gravel
Fork Micro Travel Technology Suspension Fork, Premium Carbon Blades
Rims CRD-400 Carbon, Tubeless Ready, 40mm
Hubs CRD-400
Tires WTB Raddler, 40mm
Bottom Bracket PF86 Bottom Bracket
Chainrings SRAM FORCE 1 AXS 38T
Shifters SRAM FORCE eTap AXS HRD
Rear Derailleur SRAM X01 EAGLE AXS
Cassette/Freewheel SRAM XG 1275 EAGLE 10-52T
Chain SRAM X01 Eagle
Brakes SRAM FORCE eTap AXS HRD, Centerline X Rotors (180/160)
Handlebars Easton EA70 AX
Stem BMC MSM02
Seatpost URS 01 Premium Carbon D-Shaped Seatpost, 0mm Offset
Saddle WTB SL8 Titanium Medium
Pedals Sold separately
Accessories & Extras Internal Cable Routing, Fender and Rack Mounts

* Subject to change without notice.
